Experiments / Batch 68
Batch 68 not OK
02.06.2026 ·
Mr. Mohan Yadav ·
also written as S 9076 · S 9076 #68 · BYK 9076
Application test
not OK
3 tests
Conclusion — verbatim from the source
“Results: Not OK (Gloss and Colour strength inferior).”
S 9076 #68 not ok.docx, main table
Nothing extracted for this section yet.
Reaction conditions (optimized)
other: Re-solubility tested in Ethyl Acetate + Toluene (50:50)
Sample unspecified sample
not OK
Ink application (Nitrocellulose)
| Parameter | Standard | S 9076 |
|---|---|---|
| Grinding (µm) | < 5 µm | < 5 µm |
| Colour Shade | Reference Std | As per Std |
| Transparency | Reference Std | Slightly opaque |
| Color Strength (%) | 100.00 | 98-99 |
| Viscosity (B4 Cup @26°C) | 29 s | 30 s |
| Adhesion (Tape Test) | Pass | Pass |
| Gloss @ 60° | 67.1 | 62.2 |
| Re-solubility (Rating) | 3 | 1 |
| Separation | No | No |
| Settling | No | No |
not OK
Ink application (Nitrocellulose)
| Parameter | Standard | S 9076 |
|---|---|---|
| Grinding (µm) | < 5 µm | < 5 µm |
| Colour Shade | Reference Std | Bluer |
| Transparency | Reference Std | Transparent |
| Color Strength (%) | 100.00 | 30-40 |
| Viscosity (B4 Cup @26°C) | 27 s | 29 s |
| Adhesion (Tape Test) | Pass | Pass |
| Gloss @ 60° | 8.8 | 7.9 |
| Re-solubility (Rating) | 3 | 5 |
| Separation | No | No |
| Settling | No | No |
not OK
Ink application (Nitrocellulose)
| Parameter | Standard | S 9076 |
|---|---|---|
| Grinding (µm) | < 5 µm | < 5 µm |
| Colour Shade | Reference Std | As per Std |
| Transparency | Reference Std | As per Std |
| Color Strength (%) | 100.00 | 100.00 |
| Viscosity (B4 Cup @26°C) | 32 s | 33 s |
| Adhesion (Tape Test) | Pass | Pass |
| Gloss @ 60° | 41.9 | 43.6 |
| Re-solubility (Rating) | 3 | 2 |
| Separation | No | No |
| Settling | No | No |
Test report photos
S 9076 #68 not ok.docx — 3 photos
Where this record comes from
S 9076 #68 not ok.docx
— application testing
